What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy

What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy
What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy

Large Image :  What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy

Product Details:
Place of Origin: China
Brand Name: KEGU
Model Number: Customizable
Payment & Shipping Terms:
Price: 200-500 yuan/kg
Packaging Details: Strong wooden box for Global shipping
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 2,000 pcs/month

What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy

Description
Usage: Gas Atomization Attribute: Pyrolytic Boron Nitride Crucible
Application: Vacuum Furnace Dielectric Strength: 1000 V/mil
Chemical Formula: BN Max Operating Temperature: 1000°C
Working Temperature: About 2200 Celsius Degree Color: White
Hardness: 9 On Mohs Scale Electrical Resistivity: 10^14 Ω·cm
Melting Point: 3000°C Thermal Expansion Coefficient: 1.5 X 10^-6 /K
Applications: High Temperature Insulation, Crucibles, Cutting Tools, Semiconductors Density: 2.1 G/cm3
Dielectric Constant: 4.0
Highlight:

Mechanical Seals Boron Nitride Ceramic

,

Aerospace Boron Nitride Ceramic

,

Mechanical Seals BN Ceramic

What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy 0

What is Boron Nitride Ceramic? | Properties, Uses in Semiconductor & Metallurgy 1

Product Description

Boron Nitride (BN) Ceramics represent a class of advanced engineering materials manufactured from high-purity hexagonal boron nitride (h-BN) powders through specialized sintering processes. With exceptional thermal stability in temperatures up to 2300°C in inert atmospheres and a theoretical maximum of 3000°C, these ceramics deliver outstanding thermal conductivity, remarkable dielectric strength, and excellent chemical inertness - making them the material of choice for demanding thermal management and high-performance insulation applications across high-tech industries.

Key Properties & Performance Advantages

  • Extreme Temperature Capability: Operational up to 2300°C in inert environments with exceptional thermal shock resistance

  • Superior Thermal Management: High thermal conductivity coupled with excellent electrical insulation properties

  • Exceptional Chemical Stability: Resists wetting by molten metals and maintains performance in corrosive environments

  • Advanced Mechanical Properties: Second only to diamond in hardness with low friction coefficient and self-lubricating characteristics

  • Microwave Transparency: Unique dielectric properties enable transmission of electromagnetic waves

Primary Industrial Applications

Semiconductor & Electronics Manufacturing

  • Heating elements and insulation components for crystal growth systems

  • Substrates and heat spreaders for high-power electronic devices

  • Wafer processing fixtures and diffusion source holders

Advanced Metallurgy & Materials Processing

  • Crucibles, break rings, and containers for molten metal handling

  • Continuous casting nozzles and thermocouple protection tubes

  • High-temperature furnace components and insulation systems

Aerospace & Defense Technologies

  • Radar-transparent radomes and antenna windows

  • Rocket engine components and thermal protection systems

  • Microwave communication components and waveguides

Industrial Manufacturing & Biomedical

  • High-temperature bearings, seals, and valve components

  • Cutting tools and ceramic inserts for machining applications

  • Biomedical implants utilizing exceptional biocompatibility


Contact Details
Shaanxi KeGu New Material Technology Co., Ltd

Contact Person: Ms. Yuki

Tel: 8615517781293

Send your inquiry directly to us (0 / 3000)
