200mm High Corrosion Resistant 99% Silicon Carbide Ceramic Head for Extreme Chemical Environments
Basic Properties
Place of Origin:
China
Brand Name:
KEGU
Model Number:
Customizable
Trading Properties
Minimum Order Quantity:
Negotiable
Price:
Negotiable
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Product Summary
200mm High Corrosion Resistant 99% Silicon Carbide Ceramic Head Product Overview Our high-performance silicon carbide ceramic head is manufactured using direct isostatic pressing and pressureless sintering technologies. Engineered to pair seamlessly with silicon carbide block hole systems, this ...
Product Details
Highlight:
99% Silicon Carbide Ceramics Head
,200mm Silicon Carbide Ceramics Head
,Corrosion Resistance SIC Ceramics Head
Material:
SiC
Composition:SiC:
>98%
Color:
Black
Density:
>3.05g/cm3
Max. Service Temp:
1650°C
Flexural Strength:
380MPa
Usage:
Industry Usage
Chemical Composition:
Al2O3, SiO2
Sic Content:
85%
Maximum Temperature:
1600℃
Characteristics:
High Wear Resistance
Thermal Expansion Coefficient:
4.0-4.5 × 10^-6 /K
Material Composition:
4%Si >96%Sic
Working Temperature:
1650
Advantage:
Wear And Abrasion Resistance
Purity:
98%
Material:
Silicon Carbide Ceramic
Acid Alkaline Proof:
Excellent
Solubility:
Insoluble
Open Porosity:
<0.1%
Flexural Strength:
350-550 MPa
Product Description
200mm High Corrosion Resistant 99% Silicon Carbide Ceramic Head
Product Overview
Our high-performance silicon carbide ceramic head is manufactured using direct isostatic pressing and pressureless sintering technologies. Engineered to pair seamlessly with silicon carbide block hole systems, this component forms the core of highly efficient block hole heat exchangers. Customizable inlet/outlet configurations and sealing methods are available to meet specific design requirements.
Key Applications
- Block hole heat exchangers operating in extreme acidic/alkaline environments
- Fine chemical processing equipment
- Pharmaceutical manufacturing systems
- Environmental protection and emission control systems
Technical Advantages
- Exceptional dimensional accuracy: ±1.0mm on critical dimensions, ±0.1mm thickness control
- Superior corrosion resistance: Compatible with sulfuric acid, hydrochloric acid, hydrofluoric acid, and complex mixed acid environments
- Advanced sealing technology: Features precision waterline seals with corrosion-resistant compression materials
- Extreme hardness: Second only to diamond, offering outstanding erosion resistance in particle-laden conditions
- Proven durability: 5x longer service life compared to conventional graphite heads
- Rigorous quality testing: Comprehensive factory tests including dimensional verification, 40BAR hydrostatic pressure tests, 15BAR pneumatic tests, and surface fluorescence penetration inspection
Technical Specifications
| Maximum standard outer diameter: | 300mm |
| Standard height capacity: | 200mm |
| Extended capabilities: | Outer diameter up to 600mm, maintaining 200mm height (available since 2021) |
| Customization options: | Head shapes and sealing methodologies tailored to customer drawings and specifications |
