What are Boron Nitride Ceramics? | HBN Components for Semiconductor Applications

What are Boron Nitride Ceramics? | HBN Components for Semiconductor Applications
What are Boron Nitride Ceramics? | HBN Components for Semiconductor Applications What are Boron Nitride Ceramics? | HBN Components for Semiconductor Applications What are Boron Nitride Ceramics? | HBN Components for Semiconductor Applications What are Boron Nitride Ceramics? | HBN Components for Semiconductor Applications What are Boron Nitride Ceramics? | HBN Components for Semiconductor Applications

Large Image :  What are Boron Nitride Ceramics? | HBN Components for Semiconductor Applications

Product Details:
Place of Origin: China
Brand Name: KEGU
Model Number: Customizable
Payment & Shipping Terms:
Price: 200-500 yuan/kg
Packaging Details: Strong wooden box for Global shipping
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 2,000 pcs/month

What are Boron Nitride Ceramics? | HBN Components for Semiconductor Applications

Description
Working Temperature: About 2200 Celsius Degree Thermal Conductivity: 30-50 W/mK
Attribute: Pyrolytic Boron Nitride Crucible Color: White
Advantage: Stable Thermal Shock Resistance: Good
Chemical Resistance: Excellent Hardness: 9 Mohs
Application: Industry Ceramic Dielectric Strength: 20-30 KV/mm
Feature: Ceramic Crucible Type: Ceramic Parts
Dielectric Constant: 4-5 Material: Boron Nitride
Density: 2.2-2.3 G/cm3
Highlight:

Boron Nitride Ceramic Nozzles

,

Gas Atomization Boron Nitride Ceramic

,

Amorphous BN Ceramic Nozzles

Product Description

Hexagonal Boron Nitride (HBN) ceramics deliver exceptional thermal management and electrical insulation for demanding semiconductor manufacturing processes. With graphite-like structure but superior performance, our "white graphite" components maintain structural integrity in extreme temperatures while providing excellent heat dissipation - making them ideal for critical semiconductor equipment applications.

Key Technical Advantages & Performance Features

  • Superior Thermal Management: High thermal conductivity ensures efficient heat dissipation in extreme processing environments

  • Exceptional Temperature Resistance: Maintains structural integrity and performance stability at elevated temperatures exceeding 2000°C

  • Large Component Capability: Advanced hot pressing technology enables production of large-dimension components up to 650mm diameter

  • Enhanced Material Durability: Very low porosity structure provides superior chemical resistance against corrosive semiconductor processing environments

  • Precision Manufacturing Ready: Mohs hardness of 2 allows easy machining into complex geometries with minimal post-processing

  • Net Shape Production: Direct sintering capability reduces material waste and manufacturing costs

Primary Semiconductor Equipment Applications

Gas Distribution & Process Components

  • Gas distribution plates & spray nozzles

  • Top nozzles and baffle assemblies

  • Pedestal heaters & cover plates

High-Temperature Processing Components

  • RF windows & evaporation crucibles

  • Wafer processing components & rings

  • Heat resistant substrates & base materials

Why Choose Our Boron Nitride Ceramics?

Our HBN components are precision-engineered for reliability in the most demanding semiconductor fabrication environments. The unique combination of net-shape sintering capability, large diameter manufacturing (up to 650mm), and exceptional thermal properties makes them the optimal choice for:

  • High-temperature thermal management systems

  • Corrosive environment applications

  • Precision semiconductor manufacturing

  • Custom-shaped components requiring minimal post-processing

Search-Optimized Technical Highlights

  • Boron nitride ceramics for semiconductor equipment

  • HBN components with 650mm diameter capability

  • White graphite for high-temperature applications

  • Thermally conductive electrical insulators

  • Corrosion-resistant semiconductor components
