Silicon Carbide Body Armor | NIJ Certified Plates for Personnel & Vehicles

Silicon Carbide Body Armor | NIJ Certified Plates for Personnel & Vehicles
Silicon Carbide Body Armor | NIJ Certified Plates for Personnel & Vehicles Silicon Carbide Body Armor | NIJ Certified Plates for Personnel & Vehicles Silicon Carbide Body Armor | NIJ Certified Plates for Personnel & Vehicles Silicon Carbide Body Armor | NIJ Certified Plates for Personnel & Vehicles

Large Image :  Silicon Carbide Body Armor | NIJ Certified Plates for Personnel & Vehicles

Product Details:
Place of Origin: China
Brand Name: KeGu
Model Number: Customizable
Payment & Shipping Terms:
Price: 200-500 yuan/kg
Packaging Details: Strong wooden box for Global shipping
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 2,000 pcs/month
Contact Now

Silicon Carbide Body Armor | NIJ Certified Plates for Personnel & Vehicles

Description
Material: SiC Composition:SiC: >98%
Color: Black Density: >3.05g/cm3
Max. Service Temp: 1650°C Flexural Strength: 380MPa
Highlight:

Vehicle Armor Silicon Carbide Ceramics

,

Bulletproof Silicon Carbide Ceramics

,

Body Armor Plates SIC Ceramics

Product Description

Advanced silicon carbide (SiC) ceramic armor. NIJ 0101.04 certified (Level I-IV). Multi-hit, lightweight & custom solutions for ballistic protection. Get a technical consultation.

Silicon Carbide Ceramic Armor: Superior Ballistic Protection for Modern Threats

Our silicon carbide (SiC) ceramic armor represents the pinnacle of ballistic materials technology. By combining exceptional hardness (9.5 Mohs) with significantly reduced weight, it delivers unmatched protection for personnel and vehicles against high-velocity and armor-piercing threats.

Key Ballistic Advantages

  • Multi-Hit Capability: Maintains structural integrity under successive impacts, ensuring reliability in dynamic engagements.

  • Lightweight Defense: Up to 70% lighter than steel armor at equivalent protection levels, reducing wearer fatigue and increasing mobility.

  • Full NIJ Standard Compliance: Independently certified performance across protection levels I through IV.

  • Customizable Geometry: Available in square, hexagonal, cylindrical, and other configurations to fit any armor system design.

  • Advanced Manufacturing: Utilizing both Pressureless Sintering (SSiC) and Reaction-Bonding (RSiC) to optimize performance and cost-efficiency for different threat profiles.

Technical Performance Specifications



Protection Level Test Rounds Velocity Range Certification Standard
I - III-A .22 LR - .44 Magnum 322 - 436 m/s NIJ 0101.04
III - IV 7.62mm NATO - .30 Cal AP 847 - 878 m/s NIJ 0101.04

Material Selection Guide: Choosing the Right SiC

The optimal type of silicon carbide depends on your specific requirements for ballistic performance, temperature resistance, and budget.

Silicon Carbide Body Armor | NIJ Certified Plates for Personnel & Vehicles 0

NIJ 0101.04 Standard Compliance Testing Data

The following data confirms our armor meets the rigorous standards of the National Institute of Justice.

Ballistic Test Summary

Class

Test Bullet

Bullet Weight

Velocity (m/s)

Distance (m)

Max BFD (mm)

I

.22 Caliber LR LRN

2.6 g (40 gr)

329 ± 9

5

44

I

.380 ACP FMJ RN

6.2 g (95 gr)

322 ± 9

5

44

II-A

9mm FMJ RN

8.0 g (124 gr)

341 ± 9

5

44

II-A

.40S&W FMJ RN

11.7 g (180 gr)

322 ± 9

5

44

II

9mm FMJ RN

8.0 g (124 gr)

367 ± 9

5

44

II

.357 Mag JSP

10.2 g (158 gr)

436 ± 9

5

44

III-A

9mm FMJ RN

8.2 g (124 gr)

436 ± 9

5

44

III-A

.44 Mag JHP

15.6 g (240 gr)

436 ± 9

5

44

III

7.62mm NATO FMJ

9.6 g (148 gr)

847 ± 9

15

44

IV

.30 Caliber M2 AP

10.8 g (166 gr)

878 ± 9

15

44


BFD: Back Face Signature (Trauma Impression)

Primary Applications

  • Personal Protection Systems

    • Tactical Body Armor Plates

    • Special Operations Equipment

  • Vehicle Armor Solutions

    • Light Tactical Vehicles

    • Naval Craft Protection

    • Critical Asset Shielding

Engineering & Customization Support

Our ballistic experts provide comprehensive technical consultation to integrate our ceramics into your armor solution.

  • Threat Level Assessment

  • Armor System Integration

  • Custom Shape & Geometry Development

  • Performance Validation Testing
