SiC Heater SiC Heating Element Silicon Carbide Heating Rod

SiC Heater SiC Heating Element Silicon Carbide Heating Rod
SiC Heater SiC Heating Element Silicon Carbide Heating Rod SiC Heater SiC Heating Element Silicon Carbide Heating Rod SiC Heater SiC Heating Element Silicon Carbide Heating Rod SiC Heater SiC Heating Element Silicon Carbide Heating Rod

Large Image :  SiC Heater SiC Heating Element Silicon Carbide Heating Rod

Product Details:
Place of Origin: China
Brand Name: KEGU
Model Number: Customizable
Payment & Shipping Terms:
Price: 200-500 yuan/kg
Packaging Details: Strong wooden box for Global shipping
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 2,000 pcs/month
Contact Now

SiC Heater SiC Heating Element Silicon Carbide Heating Rod

Description
Material: SiC Composition:SiC: ＞98%
Color: Black Density: ≥3.05g/cm3
Max. Service Temp: 1650℃ Flexural Strength: 380MPa
Composition:SiC: ＞85% Density: ≥3.0g/cm3
Max. Service Temp: 1380℃ Flexural Strength: 250MPa
Size: Customized Density: 2.5～2.6 G/cm3
Heat Conduction: 23.26 W/(m·℃) Resistivity: 1000～2000 Ω·mm2/m
Tensile Strength: 39.2～49 MPa Flexural Strength: 70～90 MPa
Density: 2.5~2.6g/cm³ Max. Service Temp.: 1500℃
Flexural Strength: 70-90 MPa Linear Thermal Expansion Coefficient (20-1500℃): 5×10⁻⁶/℃
Electrical Resistivity: 1000~2000Ω·mm²/m
Highlight:

customized sic heater

,

customized silicon carbide heating rod

Brand New Heating For Furnace Sic Silicon Carbide Heater Element

SiC Heater SiC Heating Element Silicon Carbide Heating Rod 0

SiC Heater SiC Heating Element Silicon Carbide Heating Rod 1

SiC Heater SiC Heating Element Silicon Carbide Heating Rod 2


FEATURES

¯¯¯¯¯¯¯¯¯¯¯¯¯¯

  • 1. Withstands as high as 1500 (surface temperature).
  • 2. Generates high heat output per unit surface area, approximately 5-10 times the output of Nichrome wire.
  • 3. High strength and excellent shock resistance.
  • 4. Heat source is free of noise and air pollution.


SiC Heater SiC Heating Element Silicon Carbide Heating Rod 3

SiC Heater SiC Heating Element Silicon Carbide Heating Rod 4SiC Heater SiC Heating Element Silicon Carbide Heating Rod 5SiC Heater SiC Heating Element Silicon Carbide Heating Rod 6SiC Heater SiC Heating Element Silicon Carbide Heating Rod 7


SiC Heater SiC Heating Element Silicon Carbide Heating Rod 8

Item RSiC NSiC SiSiC Si3N4-SiC
Bulk Density(g/cm3) 2.60-2.74 2.75-2.82 >3.02 2.68
Porosity (%) 15 10-12 <0.1 <16
Compression Strength(MPa) ≥600 600-700 -- 180
Bending Strength(MPa) 90-100(20℃) -- 250(20℃) ≥45(20℃)
100-120(1100℃) 160-180(1100℃) 280(1200℃) ≥50(1200℃)
Young’s Modulus(GPa) 280(20℃) 220-260 -- ≥16(1200℃)
Thermal Conductivity(W/MK) 26(1200℃) 15(1200℃) 45(1200℃) --
Thermal Expansion(20-1000 ℃) 4.8×10-6 5.099×10-6 4.5×10-6 ≤4.7×10-6
Max. Working Temperature(℃) 1650 1500 1380 1500
PH Resistance 1-14 -- Excellent --
Moh’s Scale of Thermal Expansion -- -- 13 --
Si3N4 (%) 0 20-40 -- ≥22
a-SiC(%) 98.5 60-80 -- ≥75
