Bulletproof Silicon Carbide Ceramics Armor For Body Armor Plates / Vehicle Armor

Bulletproof Silicon Carbide Ceramics Armor For Body Armor Plates / Vehicle Armor
Bulletproof Silicon Carbide Ceramics Armor For Body Armor Plates / Vehicle Armor Bulletproof Silicon Carbide Ceramics Armor For Body Armor Plates / Vehicle Armor Bulletproof Silicon Carbide Ceramics Armor For Body Armor Plates / Vehicle Armor Bulletproof Silicon Carbide Ceramics Armor For Body Armor Plates / Vehicle Armor

Large Image :  Bulletproof Silicon Carbide Ceramics Armor For Body Armor Plates / Vehicle Armor

Product Details:
Place of Origin: China
Brand Name: KeGu
Model Number: Customizable
Payment & Shipping Terms:
Price: 200-500 yuan/kg
Packaging Details: Strong wooden box for Global shipping
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 2,000 pcs/month
Contact Now

Bulletproof Silicon Carbide Ceramics Armor For Body Armor Plates / Vehicle Armor

Description
Material: SiC Composition:SiC: >98%
Color: Black Density: >3.05g/cm3
Max. Service Temp: 1650°C Flexural Strength: 380MPa
Highlight:

Vehicle Armor Silicon Carbide Ceramics

,

Bulletproof Silicon Carbide Ceramics

,

Body Armor Plates SIC Ceramics

Bulletproof Silicon Carbide Ceramics Armor For Ballistic Protection, Carborundum, Body Armor Plates, Vehicle Armor



Description:



Bulletproof Silicon Carbide Ceramics Armor utilizes the excellent physical properties of silicon carbide (SiC) ceramics to provide reliable ballistic protection for personnel, vehicles, and assets. Silicon carbide ceramics boast high hardness, high strength, low density, as well as good corrosion resistance and high-temperature performance, making them an ideal material for manufacturing bulletproof armor.



Feature:

1. High temperature tolerance,temperature up to 1600

2. Wear resistance

3. Corrosion resistance

4. High bending strength

5. high hardness

6.light weight

7.oxidation resistance

8.perfect efficiency of sealing

9.long time service life

10.Heat shock stability

11. Highly performance of mechanical strength

12.Cleaning or etching the hardest sub-surfaces

13.Used for grinding, lapping, and wire saw cutting as well as abrasive blasting

14.Self-lubrication

15.Lower thermal expansion coefficient

16. High thermal conductivity

17.All shape customized, can be square, hexagonal, cylindrical,or disc-like etc.

18. It is manufactured by pressureless sintering.or Reaction-Bonding



Applications:



Body Armor Plates

High-Tech Vehicle Armor Protection and Watercraft defence.



USA NIJ 0101.04 STANDARD:



Class Test-bullet Bullet Weight
(g)
(gr.)		 Bullet Velocity
(m/s)
(ft/s)		 Distance
(m)		 Max. BFD
(mm)		 No. of Shots
per Panel		 No. of Test
I .22 Caliber LR
LRN		 2.6
40		 329+-9
1080+-30		 5 44 6 4
.380 ACP
FMJ RN		 6.2
95		 322+-9
1055+-30		 5 44 6 4
II-A 9mm
FMJ RN		 8.0
124		 341+-9
1120+-30		 5 44 6 4
.40S&W
FMJ RN		 11.7
180		 322+-9
1055+-30		 5 44 6 4
II 9mm
FMJ RN		 8.0
124		 367+-9
1205+-30		 5 44 6 4
.357 Mag
JSP		 10.2
158		 436+-9
1430+-30		 5 44 6 4
III-A 9mm
FMJ RN		 8.2
124		 436+-9
1430+-30		 5 44 6 4
.44 Mag
JHP		 15.6
240		 436+-9
1430+-30		 5 44 6 4
III 7.62mm Nato
FMJ		 9.6
148		 847+-9
2780+-30		 15 44 6 2
IV .30 Calier
M2 AP		 10.8
166		 878+-9
2880+-30		 15 44 1 2





Technical data:



Properties Units RSiC SiSiC SSiC
Bulk denstity SiC Vo1% ≥99 ≥85

≥99


Bulk density g/cm3 2.60～2.72 3.01 3.10-3.15
Apparent porosity % 15 ＜0.1 ＜0.2
Modulus of rupture at 20℃ Mpa 80～90 250 400
Modulus of rupture at 1200℃ Mpa 90～100 280 650
Modulus of elasticity at 20℃ Gpa - 330 410
Thermal Conductivity at 1200℃ w.m-1.k-1 35.0 45 55
Thermal expansion at 1200℃ a×10-6/℃ 4.60 4.5 4.0
Thermal shock resistance at 1200℃   Very good Very good Very good
Max.working temperature ℃ 1650(oxid) 1350 1600



Tag:

Silicon Carbide Ceramics,

Pressureless Sintered SIC,

SIC Ceramics
