1600°C Max Temp Silicon Carbide Heating Elements with High Oxidization Resistance and Customized Sizes for Industrial Furnaces
Basic Properties
Place of Origin:
China
Brand Name:
KEGU
Model Number:
Customizable
Trading Properties
Price:
200-500 yuan/kg
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
2,000 pcs/month
Product Summary
1600°C Silicon Carbide (SiC) Heating Elements for Industrial Furnaces & Kilns High-Performance Silicon Carbide (SiC) Heating Elements for Industrial Furnaces Our Silicon Carbide (SiC) heating elements represent the pinnacle of high-temperature ceramic heating technology. Manufactured from high...
Product Details
Highlight:
Industrial Silicon Carbide Heater Elements
,Furnace Kiln SIC Heater Elements
,Electric Heating SIC Elements
Material:
SiC
Composition:SiC:
＞85%
Color:
Black
Density:
2.5~2.6g/cm³
Max. Service Temp:
1380℃
Flexural Strength:
70-90 MPa
Size:
Customized
Heat Conduction:
23.26 W/(m·℃)
Resistivity:
1000～2000 Ω·mm2/m
Tensile Strength:
39.2～49 MPa
Max. Service Temp.:
1500℃
Linear Thermal Expansion Coefficient (20-1500℃):
5×10⁻⁶/℃
Electrical Resistivity:
1000~2000Ω·mm²/m
Product Description
1600°C Silicon Carbide (SiC) Heating Elements for Industrial Furnaces & Kilns
High-Performance Silicon Carbide (SiC) Heating Elements for Industrial Furnaces
Our Silicon Carbide (SiC) heating elements represent the pinnacle of high-temperature ceramic heating technology. Manufactured from high-purity, six-party green SiC powder, they are recrystallized at extreme temperatures up to 2200°C to achieve exceptional structural integrity and performance.
Engineered for Extreme Conditions & Long Service Life
These non-metal electric heating elements are designed to deliver reliable and consistent heat in the most demanding environments. They offer a maximum operating temperature of 1600°C, with a constant working life of up to 2000 hours at 1450°C in oxidizing atmospheres, making them a cost-effective and durable solution for continuous industrial processes.
Key Advantages at a Glance
- Exceptional Temperature Resistance: Ideal for long-term operation at 1450°C, with a peak of 1600°C
- Superior Oxidization & Corrosion Resistance: Ensures stability and longevity in harsh furnace atmospheres
- Rapid Heat-Up Times: High thermal efficiency for faster process cycles and reduced energy consumption
- High Mechanical Strength & Low Deformation: Maintains structural integrity and shape under extreme heat
- Easy Installation & Maintenance: Simplified design reduces downtime and operational costs
- Compatible with Automation: Easily integrates with control systems for precise temperature profiling and adjustable heating curves, ensuring process consistency and safety
Technical Specifications
| Diameter | Length of Hot Zone | Length of Cold Zone | Overall Length | Range of Resistance |
|---|---|---|---|---|
| 8mm | 100-300mm | 60-200mm | 240-700mm | 2.1-8.6 ohms |
| 12mm | 100-400mm | 100-350mm | 300-1100mm | 0.8-5.8 ohms |
| 14mm | 100-500mm | 150-350mm | 400-1200 | 0.7-5.6 ohms |
| 16mm | 200-600mm | 200-350mm | 600-1300 | 0.7-4.4 ohms |
| 18mm | 200-800mm | 200-400mm | 600-1600 | 0.7-5.8 ohms |
| 20mm | 200-800mm | 250-600mm | 700-2000mm | 0.6-6.0 ohms |
| 25mm | 200-1200mm | 250-700mm | 700-2600mm | 0.4-5.0 ohms |
| 30mm | 300-2000mm | 250-800mm | 800-3600mm | 0.4-4.0 ohms |
| 35mm | 400-2000mm | 250-800mm | 900-3600mm | 0.5-3.6 ohms |
| 40mm | 500-2700mm | 250-800mm | 1000-4300mm | 0.5-3.4 ohms |
| 45mm | 500-3000mm | 250-750mm | 1000-4500mm | 0.3-3.0 ohms |
| 50mm | 600-2500mm | 300-750mm | 1200-4000mm | 0.3-2.5 ohms |
| 54mm | 600-2500mm | 300-750mm | 1200-4000mm | 0.3-3.0 ohms |
Wide-Ranging Industrial Applications
This versatile heater is widely used in various high-temperature electric furnaces and heating devices across multiple industries, including:
- Magnet Manufacturing
- Technical Ceramics & Powder Metallurgy
- Glass Melting & Processing
- Metallurgy & Heat Treatment
- Machinery & General Industrial Heating
