Molybdenum Disilicide Mosi2 Heating Element For Furnaces

Molybdenum Disilicide Mosi2 Heating Element For Furnaces

1. Specifications

M1700 type (d/c): dia3/6, dia4/9, dia6/12, dia9/18, dia12/24

M1800 type (d/c): dia3/6, dia4/9, dia6/12, dia9/18, dia12/24

2. Descriptions

Molybdenum disilicide (MoSi2) heating element is a resistance generate-heating component made from MoSi2 or the basic material. It is used in high temperature under the oxidizing atmosphere, it looks like glass in its surface and form a light SiO2 glass film which can protect the element not to be oxidized. So this kind of element has unique effect for resisting oxidization in the high temperature. It is used to the highest temperature up to 1800C during oxidizing atmosphere. According to your request, our company can produce the products of Pole, "U", "W" and "U"-right angle shapes, etc.

3. Installation

When installing heating element into furnaces, a separator should be placed between the two shanks of the heating element before hanging the element inside the furnace chamber. The proper separator width should be selected to fit the shanks smoothly and avoid damage to the element.

4. Packing

Mosi2 heating elements are usually packed in wooden boxes

5. Delivery

Mosi2 heating elements are usually finished producing within 5days.
