Custom 800x500mm Silicon Carbide Heat Exchanger Plate with High Corrosion and Thermal Shock Resistance

Custom 800x500mm Silicon Carbide Heat Exchanger Plate with High Corrosion and Thermal Shock Resistance
Custom 800x500mm Silicon Carbide Heat Exchanger Plate with High Corrosion and Thermal Shock Resistance Custom 800x500mm Silicon Carbide Heat Exchanger Plate with High Corrosion and Thermal Shock Resistance Custom 800x500mm Silicon Carbide Heat Exchanger Plate with High Corrosion and Thermal Shock Resistance

Large Image :  Custom 800x500mm Silicon Carbide Heat Exchanger Plate with High Corrosion and Thermal Shock Resistance

Product Details:
Place of Origin: China
Brand Name: KeGu
Model Number: Customizable
Payment & Shipping Terms:
Price: 200-500 yuan/kg
Packaging Details: Strong wooden box for Global shipping
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 2,000 pcs/month
Contact Now

Custom 800x500mm Silicon Carbide Heat Exchanger Plate with High Corrosion and Thermal Shock Resistance

Description
Material: SiC Composition:SiC: >98%
Color: Black Density: >3.05g/cm3
Max. Service Temp: 1650°C Flexural Strength: 380MPa
Usage: Industry Usage Chemical Composition: Al2O3, SiO2
Sic Content: 85% Maximum Temperature: 1600℃
Characteristics: High Wear Resistance Thermal Expansion Coefficient: 4.0-4.5 × 10^-6 /K
Material Composition: 4%Si >96%Sic Working Temperature: 1650
Advantage: Wear And Abrasion Resistance Purity: 98%
Material: Silicon Carbide Ceramic Acid Alkaline Proof: Excellent
Solubility: Insoluble Open Porosity: <0.1%
Flexural Strength: 350-550 MPa
Highlight:

800mm Length Sic Protection Sleeve

,

500mm Sic Protection Sleeve

,

Silicon Carbide Protection Sleeve

Custom 800x500mm Silicon Carbide (SiC) Heat Exchanger Plate
High Corrosion & Thermal Shock Resistance
Our custom silicon carbide heat exchanger plates represent the pinnacle of corrosion-resistant thermal technology. Manufactured from high-purity sintered silicon carbide (SSiC) through advanced isostatic pressing and pressureless sintering processes, these plates deliver unmatched performance in the most demanding chemical processing applications.
Technical Specifications & Material Properties
Property Category Parameter Unit Value
Chemical Composition Silicon Carbide (SiC) Content % > 99
Physical Properties Bulk Density kg/m³ > 3140
Apparent Porosity % < 0.5
Mechanical Properties Vickers Hardness kg/mm² 2200
Flexural Strength (3-Point) MPa 450
Compressive Strength MPa 3900
Thermal Properties Thermal Conductivity W/(m*K) 160
Coefficient of Thermal Expansion *10⁻⁶/K 4.3
Maximum Service Temperature °C 1700
Key Advantages & Performance Benefits
  • Extreme Chemical Resistance: Excellent resistance to sulfuric acid, hydrochloric acid, hydrofluoric acid, and mixed acid environments, significantly outperforming graphite and metal alloys
  • Superior Thermal Efficiency: High thermal conductivity (140-160 W/m*K) ensures rapid heat transfer and optimal energy recovery
  • Custom Engineering Solutions: Available in sizes up to 800mm * 500mm with complex micro-channel designs tailored to specific application requirements
  • Precision Manufacturing: Guaranteed dimensional accuracy of ±1.0mm with thickness tolerance of ±0.1mm for perfect system integration
  • Multiple Sealing Options: Compatible with gasket sealing, mirror finishes, or high-temperature diffusion welding for reliable pressure containment
  • Rigorous Quality Assurance: Every plate undergoes comprehensive factory inspection including fluorescent penetrant testing to ensure defect-free performance
Primary Industrial Applications
  • Chemical Processing Industry: Heat recovery and temperature control in aggressive acid and alkali environments
  • Pharmaceutical Manufacturing: Critical heat transfer in corrosive pharmaceutical production processes
  • Environmental Protection Systems: Waste acid treatment and recovery applications requiring extreme corrosion resistance
  • Specialty Chemical Production: Handling abrasive slurries and mixed acid solutions where metal alloys fail
Competitive Advantages Over Traditional Materials
Vs. Graphite: Superior mechanical strength and resistance to oxidation
Vs. Metal Alloys: Complete immunity to acid corrosion and higher temperature capability
Vs. Plastics: Significantly higher thermal conductivity and temperature resistance
Custom Design Flexibility: Engineered to customer specifications with complex internal channel geometries

Tag:

Silicon Carbide Ceramics,

Pressureless Sintered SIC,

SIC Ceramics
