High-Performance Silicon Carbide Rollers with 1650°C Service Temperature, 196 W/m*K Thermal Conductivity, and 380MPa Flexural Strength for Roller Hearth Kilns
Basic Properties
Place of Origin:
China
Brand Name:
KEGU
Model Number:
Customizable
Trading Properties
Minimum Order Quantity:
Negotiable
Price:
Negotiable
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Product Summary
High-Performance Silicon Carbide (SSiC) Rollers for Roller Hearth Kilns Enhanced Thermal Efficiency & Durability Our pressureless sintered silicon carbide (SSiC) rollers are engineered specifically for the demanding environment of roller hearth kilns. They serve as the core refractory component, ...
Product Details
Highlight:
Silicon Carbide SSiC rollers
,Roller hearth kiln rollers
,Thermal efficient ceramic rollers
Density:
>3.05g/cm3
Flexural Strength:
380MPa
Material:
SiC
Composition:SiC:
>98%
Color:
Black
Max. Service Temp:
1650°C
Usage:
Industry Usage
Chemical Composition:
Al2O3, SiO2
Sic Content:
85%
Maximum Temperature:
1600℃
Characteristics:
High Wear Resistance
Thermal Expansion Coefficient:
4.0-4.5 × 10^-6 /K
Material Composition:
4%Si >96%Sic
Working Temperature:
1650
Advantage:
Wear And Abrasion Resistance
Purity:
98%
Material:
Silicon Carbide Ceramic
Acid Alkaline Proof:
Excellent
Solubility:
Insoluble
Open Porosity:
<0.1%
Flexural Strength:
350-550 MPa
Product Description
High-Performance Silicon Carbide (SSiC) Rollers for Roller Hearth Kilns
Enhanced Thermal Efficiency & Durability
Our pressureless sintered silicon carbide (SSiC) rollers are engineered specifically for the demanding environment of roller hearth kilns. They serve as the core refractory component, delivering unmatched high-temperature performance, superior thermal conductivity, and exceptional mechanical strength to maximize your kiln's productivity, energy efficiency, and product quality in continuous, high-throughput operations.
Key Features & Benefits
- Exceptional High-Temperature Stability: Withstands continuous operation at temperatures up to 1650°C in air, maintaining structural integrity and preventing deformation.
- Superior Thermal Conductivity & Shock Resistance: Excellent heat transfer (196 W/m*K at 20°C) ensures uniform temperature distribution, while a thermal shock resistance >350°C prevents cracking during rapid temperature cycles.
- High Mechanical Strength & Wear Resistance: A high flexural strength (320-400 MPa) and extreme hardness (2350 HV) guarantee a long service life under heavy loads and abrasive conditions.
- Optimized for Efficiency: The combination of high thermal conductivity and low porosity (≈0%) translates to faster heating rates, reduced energy consumption, and consistent product quality.
Technical Specifications (SSiC Material)
| Property | Unit | Value |
|---|---|---|
| Composition: SiC | Vol% | ≥98 |
| Density | g/cm³ | ≥3.06 |
| Open Porosity | Vol% | ≈0 |
| Vickers Hardness (HV1) | kg/mm² | 2350 |
| Flexural Strength @ 20 °C | MPa | 320-400 |
| Thermal Conductivity @ 20 °C | W/(m*K) | 196 |
| Max. Service Temp (in air) | °C | 1650 |
| Thermal Shock Resistance (ΔT) | °C | >350 |
Industry Applications
Our SSiC rollers are the ideal choice for roller hearth kilns in diverse industries, including:
- Ceramics & Sanitaryware: Firing tiles, tableware, and sanitary products.
- Building Materials: Processing technical ceramics and advanced refractories.
- Metallurgy: Sintering of metal powders and heat treatment processes.
- New Energy & Electronics: Calcination of lithium battery materials and electronic ceramics.
Customization & Support
We provide tailored solutions to meet your specific kiln design and operational requirements, ensuring optimal performance and integration.
