Custom Silicon Carbide (SiC) Heating Elements
Product Overview
Our Silicon Carbide (SiC) heating elements are premium non-metallic, high-temperature heaters engineered for exceptional performance and durability. Manufactured using high-purity green silicon carbide as the base material, each element undergoes siliconization and recrystallization at ultra-high temperatures. This process creates a robust, economical heating solution ideal for reliable operation in hot, harsh, and demanding industrial environments. These elements are the preferred choice for custom electric furnace builds and advanced ceramic thermoelectric systems.
Custom Silicon Carbide Heating Elements with High-Temperature Performance and Recrystallized Structure for Electric Furnaces 0

Key Features & Benefits
  • High-Temperature Performance: Capable of continuous operation in extreme thermal conditions
  • Exceptional Durability: Recrystallized structure ensures long service life and resistance to thermal shock
  • Cost-Effective: Delivers high performance at an economical lifecycle cost
  • Versatile Design: Suitable for a wide range of furnace atmospheres and industrial processes
  • Customizable: Available in standard sizes or manufactured to your exact specifications (OD, HZ, CZ, OL, Resistance)

Technical Specifications
Outer Diameter (OD mm) Hot Zone Length (HZ mm) Cold Zone Length (CZ mm) Overall Length (OL mm) Resistance Range (Ohms)
8 100 - 300 60 - 200 240 - 700 2.1 - 8.6
12 100 - 400 100 - 350 300 - 1100 0.8 - 5.8
14 100 - 500 150 - 350 400 - 1200 0.7 - 5.6
16 200 - 600 200 - 350 600 - 1300 0.7 - 4.4
18 200 - 800 200 - 400 600 - 1600 0.7 - 5.8
20 200 - 800 250 - 600 700 - 2000 0.6 - 6.0
25 200 - 1200 250 - 700 700 - 2600 0.4 - 5.0
30 300 - 2000 250 - 800 800 - 3600 0.4 - 4.0
35 400 - 2000 250 - 800 900 - 3600 0.5 - 3.6
40 500 - 2700 250 - 800 1000 - 4300 0.5 - 3.4
45 500 - 3000 250 - 750 1000 - 4500 0.3 - 3.0
50 600 - 2500 300 - 750 1200 - 4000 0.3 - 2.5
54 600 - 2500 300 - 750 1200 - 4000 0.3 - 3.0
The table above represents part of our standard product range. We specialize in custom manufacturing Silicon Carbide heating elements to meet your unique furnace design and application requirements.
Custom Design Parameters
We can manufacture elements based on your specific needs. Key design parameters include:
  • Type: Straight Rod, U-Type, W-Type, Spiral, etc.
  • Dimensions: Outer Diameter (OD), Hot Zone (HZ), Cold Zone (CZ), Overall Length (OL)
  • Electrical Properties: Target Resistance (Ohms)
  • Geometric Specifications: For U/W types: Shank Spacing (A) and Bridge Length (D)
Custom Silicon Carbide Heating Elements with High-Temperature Performance and Recrystallized Structure for Electric Furnaces 1

Secure Packaging & Guarantee
Each Silicon Carbide heating element is protected by a four-layer packaging system designed to guarantee safe transit and delivery. This robust packaging minimizes the risk of damage during shipping.
Custom Silicon Carbide Heating Elements with High-Temperature Performance and Recrystallized Structure for Electric Furnaces 2

Primary Applications
  • Custom Industrial Electric Furnaces
  • Ceramic Sintering & Processing Kilns
  • Thermoelectric Material Production Furnaces
  • High-Temperature Laboratory & Research Ovens
  • Metallurgy and Heat Treatment Furnaces
  • Diffusion and Annealing Systems
