Zirconia Foam Ceramic Filters: The Ultimate Solution for Ultra-High Temperatures
Premium Performance
Zirconia foam filters are engineered for the most demanding high-temperature applications where thermal stability and chemical inertness are critical. As our highest-temperature product (≤1700°C), they excel in processing superalloys, titanium, and advanced steels where other filters fail.
Key Advantages
  • Max Temperature Resistance - Stable to 1700°C
  • Highest Strength - 1.5-2.5 MPa compressive strength
  • Chemical Inertness - Resists acidic & basic slags
  • Precision Filtration - Uniform pore structure for consistency
  • Advanced Applications - Ideal for aerospace, medical, and high-value components
  • Phase Stable - No destructive transformations during heating/cooling
Technical Specifications
Parameter Specification Key Benefit
Material Yttria-stabilized ZrO₂ Prevents phase transformation up to 1700°C
Color Light Yellow Easy visual identification
Max Temp ≤1700°C Industry-leading capability
Porosity 80-90% Optimal flow with thorough filtration
Density 1.0-1.5 g/cm³ Robust yet porous structure
Strength ≥1.5 MPa Handles extreme casting conditions
Thermal Expansion Low (10-11 × 10⁻⁶/°C) Minimal dimensional changes
Chemical Stability Exceptional Works with reactive metals
Primary Applications
Recommended Industries:
  • Aerospace: Superalloy turbine blades & components
  • Medical: Titanium implants & surgical instruments
  • Automotive: High-performance engine parts
  • Industrial: Tool steels & specialty alloys
Optimal For:
  • Metals: Titanium, superalloys, high-grade steels
  • Processes: Investment casting, vacuum casting
  • Requirements: High purity, fine inclusion removal
Selection Guide
Choose Zirconia When:
  1. Temperatures exceed 1500 °C
  2. Processing reactive metals (Ti, Zr, rare earths)
  3. Maximum purity is critical
  4. Chemical compatibility is essential
PPI Recommendations:
  • 10-15 PPI: High flow rates, large castings
  • 20 PPI: Balanced performance, most applications
  • 30 PPI: Maximum filtration for precision parts
Quality Assurance
  • Full stabilization confirmed by XRD analysis
  • Batch testing for consistency
  • Thermal cycling validation
  • Traceable production lots
Need help selecting the right filter?
Contact our technical team for application-specific recommendations.
